Specs

Main
MakerJPK
Maker websitehttps://www.jpk.fr
ModelJPK 45 Swing keel
First built hull2016
VersionSwing keel
Price315,000 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
Length overall13.84 m
Beam overall4.3 m
Draft maximum2.93 m
Displacement9,500 kg
Ballast weight4,000 kg
Ballast typeGlass fiber/vinylester (infusion) fin with lead bulb
Helm2 wheels
Rudder2 spade rudders
CockpitOpen aft cockpit
Designer
Naval architect
Name/StudioJacques Valer
Rig & Sails
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing riggingDyform
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area112.97 sq.m
Downwind sail area257.99 sq.m
Engine
Engine A
Power65 HP
TypeInboard
Storage
Fuel tank A400.12 liter
Water tank A799.86 liter
Water heater A40.13 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 25.61
Upwind SA to Displacement25.61
Downwind SA to Displacement58.48
Ballast to Displacement (B/D) 0.42
Capsize Screening Formula (CSF) 2.05
