Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.63 m
Specs
Main
Name | Value |
---|---|
Maker | JPK |
Maker website | https://www.jpk.fr |
Model | JPK 960 |
First built hull | 2003 |
Price | 81,500 € |
Boat type | Sail |
Category | Cruiser/Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.46 kmh |
Length overall | 9.63 m |
Length at waterline | 8.6 m |
Beam overall | 3.51 m |
Headroom | 1.83 m |
Draft maximum | 1.98 m |
Displacement | 3,400.13 kg |
Ballast weight | 1,399.78 kg |
Ballast type | Cast iron fin with lead bulb |
Helm | 1 tiller |
Rudder | 2 transom hung rudders |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Jacques Valer |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 56.02 sq.m |
Downwind sail area | 121.98 sq.m |
Mainsail A | 344.00 |
Spinnaker A | 818.00 |
Spinnaker A | 969.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 18 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.07 |
Upwind SA to Displacement | 25.2 |
Downwind SA to Displacement | 54.87 |
Hull Displacement Speed | 0.07 |
Displacement to Length (D/L) | 7.12 |
Ballast to Displacement (B/D) | 0.41 |
Capsize Screening Formula (CSF) | 2.35 |
