Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10 m
Specs
Main
Name | Value |
---|---|
Maker | JPK |
Maker website | https://www.jpk.fr |
Model | JPK 998 |
First built hull | 2008 |
Price | 99,000 € |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 12.02 kmh |
Length overall | 10 m |
Length at waterline | 9.48 m |
Beam overall | 2.77 m |
Headroom | 1.74 m |
Draft maximum | 1.86 m |
Displacement | 2,699.78 kg |
Ballast weight | 1,349.89 kg |
Ballast type | Steel fin with lead bulb |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Open aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Jacques Valer |
Rig & Sails
Name | Value |
---|---|
Spars | Mast in Carbon fiber and boom in Aluminum |
Standing rigging | Single-strand (ROD) |
Number of spreaders | 2 |
Upwind sail area | 64.01 sq.m |
Downwind sail area | 142.98 sq.m |
Mainsail A | 409.00 |
Spinnaker A | 1023.00 |
Spinnaker A | 1130.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 13 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.09 |
Upwind SA to Displacement | 33.58 |
Downwind SA to Displacement | 75 |
Hull Displacement Speed | 0.09 |
Displacement to Length (D/L) | 7.47 |
Ballast to Displacement (B/D) | 0.5 |
Capsize Screening Formula (CSF) | 2.01 |
