Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
6 m
Specs
Main
Name | Value |
---|---|
Maker | Kelt Sailboats |
Model | Kelt 5.50 Lifting keel |
First built hull | 1978 |
Version | Lifting keel |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 8.56 kmh |
Mast height | 8.41 m |
Length overall | 6 m |
Length at waterline | 4.82 m |
Beam overall | 2.17 m |
Headroom | 1.43 m |
Draft maximum | 1.13 m |
Displacement | 934.85 kg |
Ballast weight | 600.1 kg |
Ballast type | Lead |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Closed aft cockpit |
Unsinkable | |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Gilles Ollier |
Rig & Sails
Name | Value |
---|---|
Mast | 27.6 |
Spars | Mast and boom in Aluminum |
Standing rigging | Continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 18.49 sq.m |
Downwind sail area | 29.08 sq.m |
Mainsail A | 113.00 |
Spinnaker A | 199.00 |
Spinnaker A | 59.00 |
Spinnaker A | 31.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard Engine |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 19.66 |
Downwind SA to Displacement | 30.93 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 5.33 |
Ballast to Displacement (B/D) | 0.64 |
Capsize Screening Formula (CSF) | 2.24 |
