Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.04 m
Specs
Main
Name | Value |
---|---|
Maker | Kelt Sailboats |
Model | Kelt 6.20 Fin keel |
First built hull | 1974 |
Version | Fin keel |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 8.9 kmh |
Mast height | 8.78 m |
Length overall | 7.04 m |
Length at waterline | 5.21 m |
Beam overall | 2.47 m |
Headroom | 1.46 m |
Draft maximum | 1.1 m |
Displacement | 1,025.12 kg |
Ballast weight | 350.17 kg |
Ballast type | Cast iron |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Closed aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Philippe Harlé |
Rig & Sails
Name | Value |
---|---|
Mast | 28.8 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | 0 ° |
Upwind sail area | 23.69 sq.m |
Downwind sail area | 41.34 sq.m |
Mainsail A | 95.00 |
Spinnaker A | 350.00 |
Spinnaker A | 93.00 |
Spinnaker A | 30.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 23.7 |
Downwind SA to Displacement | 41.35 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 5.54 |
Ballast to Displacement (B/D) | 0.34 |
Capsize Screening Formula (CSF) | 2.47 |
