Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.29 m
Specs
Main
| Maker | Kelt Sailboats |
| Model | Kelt 7.60 Keel and centerboard |
| First built hull | 1979 |
| Version | Keel and centerboard |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 10.11 kmh |
| Mast height | 9.94 m |
| Length overall | 8.29 m |
| Length at waterline | 6.71 m |
| Beam overall | 2.77 m |
| Beam hull | 1.83 m |
| Draft maximum | 1.68 m |
| Displacement | 2,629.93 kg |
| Ballast weight | 780.18 kg |
| Ballast type | Cast iron exterior ballast with steel centerboard |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Jean Berret |
| Website | http://www.berret-racoupeau.com/ |
Rig & Sails
| Mast | 32.6 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 37.81 sq.m |
| Downwind sail area | 64.2 sq.m |
Engine
| Engine A | |
| Power | 10 HP |
| Type | outboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 20.18 |
| Downwind SA to Displacement | 34.27 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.29 |
| Ballast to Displacement (B/D) | 0.3 |
| Capsize Screening Formula (CSF) | 2.03 |
