Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.29 m
Specs
Main
Name | Value |
---|---|
Maker | Kelt Sailboats |
Model | Kelt 7.60 Keel and centerboard |
First built hull | 1979 |
Version | Keel and centerboard |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 10.11 kmh |
Mast height | 9.94 m |
Length overall | 8.29 m |
Length at waterline | 6.71 m |
Beam overall | 2.77 m |
Headroom | 1.83 m |
Draft maximum | 1.68 m |
Displacement | 2,629.93 kg |
Ballast weight | 780.18 kg |
Ballast type | Cast iron exterior ballast with steel centerboard |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Jean Berret |
Website | http://www.berret-racoupeau.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 32.6 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | 0 ° |
Upwind sail area | 37.81 sq.m |
Downwind sail area | 64.2 sq.m |
Mainsail A | 131.00 |
Spinnaker A | 560.00 |
Spinnaker A | 90.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 10 HP |
Type | Outboard Engine ; Gas |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 20.18 |
Downwind SA to Displacement | 34.27 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 6.29 |
Ballast to Displacement (B/D) | 0.3 |
Capsize Screening Formula (CSF) | 2.03 |
