Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.26 m
Specs
Main
Name | Value |
---|---|
Maker | Kelt Sailboats |
Model | Kelt 8.50 Centerboard (Trunk) |
First built hull | 1983 |
Version | Centerboard (Trunk) |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 10.7 kmh |
Length overall | 8.26 m |
Length at waterline | 7.53 m |
Beam overall | 3.11 m |
Draft maximum | 0.64 m |
Displacement | 3,200.09 kg |
Ballast weight | 1,500.03 kg |
Ballast type | Cast iron interior ballast with steel centerboard |
Helm | 1 tiller |
Rudder | 1 semi-spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Gilles Vaton |
Website | http://www.vaton-design.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 44.97 sq.m |
Downwind sail area | 82.03 sq.m |
Mainsail A | 205.00 |
Spinnaker A | 678.00 |
Spinnaker A | 158.00 |
Spinnaker A | 39.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 15 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 21.06 |
Downwind SA to Displacement | 38.42 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 6.66 |
Ballast to Displacement (B/D) | 0.47 |
Capsize Screening Formula (CSF) | 2.13 |
