2015 Celtic Marine Monotype 7.50

Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerCeltic Marine
Maker websitehttps://www.celticmarine.com
ModelMonotype 7.50
First built hull2015
Price30,200 €
Boat typeSail
CategorySports Cruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed10.22 kmh
Mast height10.61 m
Length overall7.53 m
Length at waterline6.89 m
Beam overall1.86 m
Draft maximum1.22 m
Displacement800 kg
Ballast weight475 kg
Helm1 tiller
Rudder1 spade rudder
CockpitOpen aft cockpit
Trailerable
Designer
Naval architect
Name/StudioGilles Bréteché
Rig & Sails
Mast34.8
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle20 °
Upwind sail area22.76 sq.m
Downwind sail area54.91 sq.m
Engine
Engine A
TypeOutboard
Storage

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 26.85
Upwind SA to Displacement26.85
Downwind SA to Displacement64.77
Hull Displacement Speed 6.37
Displacement to Length (D/L) 68.22
Ballast to Displacement (B/D) 0.59
Capsize Screening Formula (CSF) 2.02
