Boat Overview

Boat Description

Elegant Luxury...

We at Lagoon have strived to produce a catamaran where harmony reigns superior between interior and exterior living. Compromise does not exist aboard the SEVENTY 7, innovation has enhanced your comfort and performance for a seafaring life.

With an illustrious team brought together by Lagoon-VPLP and Nauta Design, the SEVENTY 7 catamaran yacht marks an important step towards a boating world in which elegance and refinement are the staples of design.

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerLagoon
Maker websitehttps://www.cata-lagoon.com
ModelSeventy 7
First built hull2016
Price2,850,000 €
Boat typeSail
CategoryFlybridge BoatsDaysailer BoatsCatamaran Boats
Hull typeCatamaran Boats
Hull materialFiberglass
Cabins6
Births14
Heads6
General
Mast height36.61 m
Length overall23.26 m
Length at waterline23.1 m
Beam overall11 m
Beam hull2.19 m
Draft maximum1.92 m
Displacement61,660 kg
HelmTwin helm wheels
RudderTwin spade rudders
CockpitAft cockpit and flybridge
CE classification A14
CE classification B18
CE classification C24
CE classification D40
Designer
Naval architect
Name/StudioVPLP Design
Websitehttp://www.vplp.fr
Exterior designer
Name/StudioPatrick le Quement
Interior designer
Name/StudioNauta Design
Websitehttps://www.nautadesign.com
Rig & Sails
Mast120.1
SparsAluminum spars
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area335.38 sq.m
Downwind sail area662.96 sq.m
Engine
Engine A
FuelDiesel
Power230 HP
TypeInboard
Engine B
FuelDiesel
Power230 HP
TypeInboard
Storage
Fuel tank A2,800.07 liter
Water tank A1,600.09 liter
Holding tank A599.99 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 21.85
Upwind SA to Displacement21.85
Downwind SA to Displacement43.19
Hull Displacement Speed 11.67
Displacement to Length (D/L) 139.34
Capsize Screening Formula (CSF) 2.81
