Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.35 m
Specs
Main
Name | Value |
---|---|
Maker | Laser Performance |
Maker website | https://www.laserperformance.us |
Model | Laser 5000 |
First built hull | 1992 |
Boat type | Sail |
Category | Dinghy Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 7.35 m |
Beam overall | 3.05 m |
Draft maximum | 1.13 m |
Displacement | 170.1 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Aft cockpit with racks |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Phil Morisson |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | Continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 20.81 sq.m |
Downwind sail area | 48.03 sq.m |
Mainsail A | 162.00 |
Spinnaker A | 355.00 |
Spinnaker A | 62.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.19 |
Upwind SA to Displacement | 68.93 |
Downwind SA to Displacement | 159.09 |
Hull Displacement Speed | 0.19 |
Capsize Screening Formula (CSF) | 5.55 |
