2015 Leopard Catamarans 51 Powercat
Preview

Boat Overview

  • Type
    power
  • Maker
    Leopard Catamarans
  • Hull type
    catamaran
  • Hull Material
    composite_material
  • Category
    -
  • Boat length (LOA)
    15.54 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerLeopard Catamarans
Maker websitehttps://www.leopardcatamarans.com/
Model51 Powercat
First built hull2015
Last built hull-
Version-
Price465000 GBP
Boat typepower
Category-
Hull typecatamaran
Hull materialcomposite_material
Cabins-
Births-
Heads-
General
NameValue
Top speed-
Cruising speed-
Mast height-
Length overall15.54 m
Length at waterline14.96 m
Beam overall7.65 m
Beam center-line-
Beam hull-
Headroom-
Bridgedeck clearance-
Nominal bridgedeck clearance-
Draft maximum1.01 m
Draft minimum-
Displacement18497.05 kg
Tonnage Gross-
Tonnage Net-
Ballast weight-
Ballast type-
Helm-
Rudder-
Hull appendages
Hull appendages A-
Cockpit-
Unsinkable-
Trailerable-
CE classification
CE classification A-
CE classification B-
CE classification C-
CE classification D-
Designer
NameValue
Naval architect
Name/StudioAlexander Simonis ; Maarten Voogd
Websitehttp://www.simonis-voogd.com/
Exterior designer
Name/Studio-
Website-
Interior designer
Name/Studio-
Website-
Rig & Sails
NameValue
Rigging-
Rotating spars-
Mast-
Spars-
Standing rigging-
Number of spreaders-
Spreaders angle-
Upwind sail area-
Downwind sail area-
Mainsail
Mainsail A-
Headsail
Headsail A-
Spinnaker
Spinnaker A-
Engine
NameValue
Engine A
MakerYanmar
Website-
Model8LV350
TypeInboard engine ; Diesel
Drive-
Fuel-
Power370
Power Typehp
Engine B
MakerYanmar
Website-
Model8LV350
TypeInboard engine ; Diesel
Drive-
Fuel-
Power370
Power Typehp
Storage
NameValue
Fuel tank
Fuel tank A1498.86 liter
Water tank
Water tank A779.71 liter
Holding tank
Holding tank A-
Water heater
Water heater A-

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) -
Upwind SA to Displacement-
Downwind SA to Displacement-
Hull Displacement Speed 9.39
Displacement to Length (D/L) 153.82
Ballast to Displacement (B/D) -
Capsize Screening Formula (CSF) 2.92
Stability Speed-
Kelsall Stability Index (KSI)-
