Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
6.04 m
Specs
Main
Name | Value |
---|---|
Maker | Lite Boat |
Maker website | https://www.liteboat.com |
Model | Lite XP |
First built hull | 2018 |
Boat type | Sail |
Category | Dinghy Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Mast height | 7.53 m |
Length overall | 6.04 m |
Beam overall | 1.55 m |
Draft maximum | 1.1 m |
Displacement | 410.05 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Open aft cockpit |
Unsinkable | |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Samuel Manuard |
Website | http://sam.manuard.free.fr/ |
Rig & Sails
Name | Value |
---|---|
Mast | 24.7 |
Spars | Mast and boom in Carbon fiber |
Standing rigging | No standing rigging |
Upwind sail area | 10.03 sq.m |
Downwind sail area | 21 sq.m |
Mainsail A | 108.00 |
Mainsail B | 118.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 18.49 |
Downwind SA to Displacement | 38.68 |
Hull Displacement Speed | 0.05 |
Capsize Screening Formula (CSF) | 2.11 |
