Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerLite Boat
Maker websitehttps://www.liteboat.com
ModelLite XP
First built hull2018
Boat typeSail
CategoryDinghy Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Mast height7.53 m
Length overall6.04 m
Beam overall1.55 m
Draft maximum1.1 m
Displacement410.05 kg
Helm1 tiller
Rudder1 transom hung rudder
CockpitOpen aft cockpit
Unsinkable
Trailerable
Designer
NameValue
Naval architect
Name/StudioSamuel Manuard
Websitehttp://sam.manuard.free.fr/
Rig & Sails
NameValue
Mast24.7
SparsMast and boom in Carbon fiber
Standing riggingNo standing rigging
Upwind sail area10.03 sq.m
Downwind sail area21 sq.m
Mainsail A108.00
Mainsail B118.00
Engine
NameValue
Engine A
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement18.49
Downwind SA to Displacement38.68
Hull Displacement Speed 0.05
Capsize Screening Formula (CSF) 2.11
