Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
5.18 m
Specs
Main
Name | Value |
---|---|
Maker | Marlow Hunter |
Maker website | https://www.marlow-hunter.com |
Model | Hunter 170 |
First built hull | 1999 |
Boat type | Sail |
Category | Dinghy Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Mast height | 7.8 m |
Length overall | 5.18 m |
Beam overall | 2.13 m |
Draft maximum | 1.4 m |
Displacement | 218.18 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Open aft cockpit |
Unsinkable | |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Hunter Design |
Website | http://www.marlow-hunter.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 25.6 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 13.94 sq.m |
Downwind sail area | 27.96 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard Engine |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.09 |
Upwind SA to Displacement | 39.1 |
Downwind SA to Displacement | 78.46 |
Hull Displacement Speed | 0.09 |
Capsize Screening Formula (CSF) | 3.58 |
