Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerMarlow Hunter
Maker websitehttps://www.marlow-hunter.com
ModelHunter 33 - 2004 Deep draft
First built hull2004
VersionDeep draft
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed11.7 kmh
Mast height14.23 m
Length overall10.24 m
Length at waterline8.99 m
Beam overall3.54 m
Beam hull1.95 m
Draft maximum1.71 m
Displacement4,658 kg
Ballast weight1,569 kg
Ballast typeCast iron
Helm1 wheel
Rudder1 spade rudder
CockpitClosing aft cockpit with opening system
Designer
Naval architect
Name/StudioHunter Design ; Glenn Henderson
Websitehttp://www.marlow-hunter.com/
Rig & Sails
Mast46.7
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angleSwept-back (Bergström)
Upwind sail area58.06 sq.m
Engine
Engine A
Power29 HP
TypeInboard
Storage
Fuel tank A95.01 liter
Water tank A188.89 liter
Holding tank A95.01 liter
Water heater A18.93 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 21.17
Upwind SA to Displacement21.17
Hull Displacement Speed 7.28
Displacement to Length (D/L) 178.57
Ballast to Displacement (B/D) 0.34
Capsize Screening Formula (CSF) 2.14
