Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
5.61 m
Specs
Main
Name | Value |
---|---|
Maker | Marlow Hunter |
Maker website | https://www.marlow-hunter.com |
Model | Marlow Hunter 18 |
First built hull | 2011 |
Boat type | Sail |
Category | Daysailer Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 8.75 kmh |
Mast height | 7.5 m |
Length overall | 5.61 m |
Length at waterline | 5.06 m |
Beam overall | 2.19 m |
Headroom | 1.98 m |
Draft maximum | 1.34 m |
Displacement | 802.86 kg |
Ballast weight | 3,999.77 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Open aft cockpit |
Unsinkable | |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Glenn Henderson |
Rig & Sails
Name | Value |
---|---|
Mast | 24.6 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 15.79 sq.m |
Downwind sail area | 35.4 sq.m |
Mainsail A | 291.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 18.59 |
Downwind SA to Displacement | 41.67 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 5.46 |
Ballast to Displacement (B/D) | 4.98 |
Capsize Screening Formula (CSF) | 2.38 |
