Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.24 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Marlow Hunter |
| Maker website | https://www.marlow-hunter.com |
| Model | Marlow Hunter 33 Shoal draft |
| First built hull | 2011 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Name | Value |
|---|---|
| Top speed | 11.7 kmh |
| Length overall | 10.24 m |
| Length at waterline | 8.99 m |
| Beam overall | 3.54 m |
| Headroom | 2.01 m |
| Draft maximum | 1.4 m |
| Displacement | 5,624.09 kg |
| Ballast weight | 1,622.95 kg |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closing aft cockpit with opening system |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Glenn Henderson |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back (Bergström) |
| Upwind sail area | 58.06 sq.m |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 29 HP |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Upwind SA to Displacement | 18.67 |
| Displacement to Length (D/L) | 7.28 |
| Ballast to Displacement (B/D) | 0.29 |
| Capsize Screening Formula (CSF) | 2.01 |
