Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
6.1 m
Specs
Main
Name | Value |
---|---|
Maker | Marstrom |
Maker website | https://www.marstrom.com |
Model | Marström M20 |
First built hull | 2001 |
Boat type | Sail |
Category | Catamaran Boats |
Hull type | Catamaran Boats |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Length overall | 6.1 m |
Beam overall | 3.05 m |
Displacement | 115.21 kg |
Helm | 1 tiller |
Rudder | 2 transom hung rudders |
Cockpit | No cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Göran Marström |
Website | http://www.marstrom.com/ |
Rig & Sails
Name | Value |
---|---|
Rotating spars | |
Spars | Mast and boom in Carbon fiber |
Upwind sail area | 22.02 sq.m |
Downwind sail area | 44.04 sq.m |
Mainsail A | 237.00 |
Spinnaker A | 237.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.23 |
Upwind SA to Displacement | 94.56 |
Downwind SA to Displacement | 189.11 |
Hull Displacement Speed | 0.23 |
Capsize Screening Formula (CSF) | 6.32 |
