Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.32 m
Specs
Main
Name | Value |
---|---|
Maker | Melges |
Maker website | https://www.melges.com |
Model | Melges 24 |
First built hull | 1993 |
Price | 42,900 € |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 10.12 kmh |
Length overall | 7.32 m |
Length at waterline | 6.71 m |
Beam overall | 2.5 m |
Draft maximum | 1.52 m |
Displacement | 809.21 kg |
Ballast weight | 294.83 kg |
Ballast type | Lead |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Open aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Reichel Pugh Yacht Design |
Website | https://www.reichel-pugh.com |
Rig & Sails
Name | Value |
---|---|
Spars | Mast in Carbon fiber and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 32.98 sq.m |
Downwind sail area | 76.92 sq.m |
Mainsail A | 226.00 |
Mainsail B | 129.00 |
Spinnaker A | 602.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard Engine |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.11 |
Upwind SA to Displacement | 38.62 |
Downwind SA to Displacement | 90.08 |
Hull Displacement Speed | 0.11 |
Displacement to Length (D/L) | 6.29 |
Ballast to Displacement (B/D) | 0.36 |
Capsize Screening Formula (CSF) | 2.71 |
