Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
4.72 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Nacra Sailing |
| Maker website | https://www.nacrasailing.com |
| Model | Nacra 15 |
| First built hull | 2015 |
| Price | 14,000 € |
| Boat type | Sail |
| Category | Catamaran Boats |
| Hull type | Catamaran Boats |
| Hull material | Composite_Material |
General
| Name | Value |
|---|---|
| Length overall | 4.72 m |
| Beam overall | 2.38 m |
| Draft maximum | 1.04 m |
| Displacement | 140.16 kg |
| Helm | 1 tiller |
| Rudder | 2 transom hung rudders |
| Cockpit | No cockpit |
| Trailerable |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Gino Morrelli ; Pete Melvin |
| Website | http://www.morrellimelvin.com/ |
Rig & Sails
| Name | Value |
|---|---|
| Rotating spars | |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back (diamond) |
| Upwind sail area | 16.91 sq.m |
| Downwind sail area | 30.1 sq.m |
| Mainsail A | 146.00 |
| Spinnaker A | 178.00 |
| Spinnaker A | 36.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.14 |
| Upwind SA to Displacement | 63.72 |
| Downwind SA to Displacement | 113.43 |
| Hull Displacement Speed | 0.14 |
| Capsize Screening Formula (CSF) | 4.62 |
