Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
6.22 m
Specs
Main
Name | Value |
---|---|
Maker | Nacra Sailing |
Maker website | https://www.nacrasailing.com |
Model | Nacra F20 FCS |
First built hull | 2014 |
Price | 30,800 € |
Boat type | Sail |
Category | Catamaran Boats |
Hull type | Catamaran Boats |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 6.22 m |
Beam overall | 3.23 m |
Displacement | 170.1 kg |
Helm | 2 tillers |
Rudder | 2 rudders on amas with T-foils |
Cockpit | No cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Gino Morrelli ; Pete Melvin |
Website | http://www.morrellimelvin.com/ |
Rig & Sails
Name | Value |
---|---|
Rotating spars | |
Spars | Mast and boom in Carbon fiber |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back (diamond) |
Upwind sail area | 26.2 sq.m |
Downwind sail area | 48.96 sq.m |
Mainsail A | 226.00 |
Mainsail B | 56.00 |
Spinnaker A | 301.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.2 |
Upwind SA to Displacement | 86.78 |
Downwind SA to Displacement | 162.17 |
Hull Displacement Speed | 0.2 |
Capsize Screening Formula (CSF) | 5.89 |
