Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
5.24 m
Specs
Main
Name | Value |
---|---|
Maker | Nacra Sailing |
Maker website | https://www.nacrasailing.com |
Model | Nacra Inter 17 |
First built hull | 1998 |
Boat type | Sail |
Category | Catamaran Boats |
Hull type | Catamaran Boats |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 5.24 m |
Beam overall | 2.5 m |
Displacement | 140.16 kg |
Helm | 1 tiller |
Rudder | 2 transom hung rudders |
Cockpit | No cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Roscoe Guinea |
Rig & Sails
Name | Value |
---|---|
Rotating spars | |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Upwind sail area | 13.84 sq.m |
Downwind sail area | 30.84 sq.m |
Mainsail A | 149.00 |
Spinnaker A | 183.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.14 |
Upwind SA to Displacement | 52.17 |
Downwind SA to Displacement | 116.23 |
Hull Displacement Speed | 0.14 |
Capsize Screening Formula (CSF) | 4.86 |
