Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.78 m
Specs
Main
| Maker | Nauticat Yachts |
| Maker website | https://www.nauticat.com |
| Model | Nauticat 321 Standard |
| First built hull | 1999 |
| Version | Standard |
| Price | 198,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.25 kmh |
| Mast height | 13.84 m |
| Length overall | 9.78 m |
| Length at waterline | 8.29 m |
| Beam overall | 3.26 m |
| Draft maximum | 1.68 m |
| Displacement | 6,200.15 kg |
| Ballast weight | 1,999.89 kg |
| Ballast type | Lead |
| Helm | 2 wheels |
| Rudder | 1 semi-spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Design Office Siltala |
| Website | http://www.nauticat.com |
Rig & Sails
| Mast | 45.4 |
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 53.51 sq.m |
| Downwind sail area | 102.29 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 39 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 16.13 |
| Downwind SA to Displacement | 30.83 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.99 |
| Ballast to Displacement (B/D) | 0.32 |
| Capsize Screening Formula (CSF) | 1.79 |
