Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.09 m
Specs
Main
| Maker | Nauticat Yachts |
| Maker website | https://www.nauticat.com |
| Model | Nauticat 33 |
| First built hull | 1967 |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.46 kmh |
| Mast height | 12.92 m |
| Length overall | 10.09 m |
| Length at waterline | 8.6 m |
| Beam overall | 3.29 m |
| Draft maximum | 1.25 m |
| Displacement | 7,500.14 kg |
| Ballast weight | 1,850.2 kg |
| Helm | 2 wheels |
| Rudder | 1 rudder on skeg |
| Cockpit | Raised aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Wilho Aarnipalo |
Rig & Sails
| Mast | 42.4 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 48.03 sq.m |
| Downwind sail area | 78.5 sq.m |
Engine
| Engine A | |
| Power | 80 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.03 |
| Upwind SA to Displacement | 12.75 |
| Downwind SA to Displacement | 20.84 |
| Hull Displacement Speed | 0.03 |
| Displacement to Length (D/L) | 7.12 |
| Ballast to Displacement (B/D) | 0.25 |
| Capsize Screening Formula (CSF) | 1.7 |
