Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.39 m
Specs
Main
| Maker | Nauticat Yachts |
| Maker website | https://www.nauticat.com |
| Model | Nauticat 331 Deep draft |
| First built hull | 1999 |
| Version | Deep draft |
| Price | 235,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.46 kmh |
| Mast height | 13.75 m |
| Length overall | 10.39 m |
| Length at waterline | 8.6 m |
| Beam overall | 3.41 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.58 m |
| Displacement | 8,300 kg |
| Ballast weight | 2,400 kg |
| Helm | 2 wheels |
| Rudder | 1 semi-spade rudder |
| Cockpit | Raised aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Design Office Siltala |
| Website | http://www.nauticat.com |
Rig & Sails
| Mast | 45.11 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 61.59 sq.m |
| Downwind sail area | 92.72 sq.m |
Engine
| Engine A | |
| Power | 75 HP |
| Type | Inboard |
Storage
| Fuel tank A | 450.09 liter |
| Water tank A | 450.09 liter |
| Holding tank A | 79.87 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.03 |
| Upwind SA to Displacement | 15.28 |
| Downwind SA to Displacement | 23 |
| Hull Displacement Speed | 0.03 |
| Displacement to Length (D/L) | 7.12 |
| Ballast to Displacement (B/D) | 0.29 |
| Capsize Screening Formula (CSF) | 1.7 |
