Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.39 m
Specs
Main
Name | Value |
---|---|
Maker | Nauticat Yachts |
Maker website | https://www.nauticat.com |
Model | Nauticat 331 Shoal draft |
First built hull | 1999 |
Version | Shoal draft |
Price | 235,000 € |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.46 kmh |
Mast height | 13.75 m |
Length overall | 10.39 m |
Length at waterline | 8.6 m |
Beam overall | 3.41 m |
Headroom | 1.56 m |
Draft maximum | 1.25 m |
Displacement | 8,299.83 kg |
Ballast weight | 2,399.96 kg |
Helm | 2 wheels |
Rudder | 1 semi-spade rudder |
Cockpit | Raised aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Design Office Siltala |
Website | http://www.nauticat.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 45.11 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | 0 ° |
Upwind sail area | 61.59 sq.m |
Downwind sail area | 92.72 sq.m |
Mainsail A | 234.00 |
Spinnaker A | 667.00 |
Spinnaker A | 105.00 |
Spinnaker A | 84.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 75 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.03 |
Upwind SA to Displacement | 15.28 |
Downwind SA to Displacement | 23 |
Hull Displacement Speed | 0.03 |
Displacement to Length (D/L) | 7.12 |
Ballast to Displacement (B/D) | 0.29 |
Capsize Screening Formula (CSF) | 1.7 |
