Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.39 m
Specs
Main
| Maker | Nauticat Yachts |
| Maker website | https://www.nauticat.com |
| Model | Nauticat 351 |
| First built hull | 2006 |
| Price | 290,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.75 kmh |
| Mast height | 15.27 m |
| Length overall | 10.39 m |
| Length at waterline | 9.08 m |
| Beam overall | 3.54 m |
| Draft maximum | 1.56 m |
| Displacement | 7,500 kg |
| Ballast weight | 2,700 kg |
| Ballast type | Lead |
| Helm | 2 wheels |
| Rudder | 1 semi-spade rudder |
| Cockpit | Raised aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Design Office Siltala |
| Website | http://www.nauticat.com |
Rig & Sails
| Mast | 50.11 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 67.73 sq.m |
| Downwind sail area | 124.21 sq.m |
Engine
| Engine A | |
| Power | 54 HP |
| Type | Inboard |
Storage
| Fuel tank A | 335.01 liter |
| Water tank A | 439.86 liter |
| Holding tank A | 90.09 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 17.98 |
| Downwind SA to Displacement | 32.97 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 7.31 |
| Ballast to Displacement (B/D) | 0.36 |
| Capsize Screening Formula (CSF) | 1.82 |
