Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
15.45 m
Specs
Main
Name | Value |
---|---|
Maker | Nauticat Yachts |
Maker website | https://www.nauticat.com |
Model | Nauticat 515 |
First built hull | 1997 |
Price | 820,000 € |
Boat type | Sail |
Category | Cruiser BoatsCenter Cockpit Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 13.65 kmh |
Mast height | 23.5 m |
Length overall | 15.45 m |
Length at waterline | 12.22 m |
Beam overall | 4.6 m |
Draft maximum | 2.19 m |
Displacement | 24,000.01 kg |
Ballast weight | 8,200.04 kg |
Ballast type | Lead |
Helm | 2 wheels |
Rudder | 1 semi-spade rudder |
Cockpit | Central cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Kaj Gustaffson |
Rig & Sails
Name | Value |
---|---|
Mast | 77.1 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Number of spreaders | 3 |
Spreaders angle | 0 ° |
Upwind sail area | 137.68 sq.m |
Downwind sail area | 267.38 sq.m |
Mainsail A | 636.00 |
Spinnaker A | 2242.00 |
Spinnaker A | 245.00 |
Spinnaker A | 166.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 160 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 16.83 |
Downwind SA to Displacement | 32.69 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 8.49 |
Ballast to Displacement (B/D) | 0.34 |
Capsize Screening Formula (CSF) | 1.61 |
