Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
16.49 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | Club Swan 50 |
| First built hull | 2016 |
| Price | 1,100,000 € |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 14.61 kmh |
| Length overall | 16.49 m |
| Length at waterline | 13.75 m |
| Beam overall | 3.99 m |
| Draft maximum | 3.54 m |
| Displacement | 8,499.86 kg |
| Ballast weight | 3,400.13 kg |
| Ballast type | Carbon fiber fin with lead bulb |
| Helm | 2 wheels |
| Rudder | 2 spade rudders |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Juan Kouyoumdjian |
| Website | http://www.juanyachtdesign.com/ |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 158.03 sq.m |
| Downwind sail area | 362.97 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 75 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.11 |
| Upwind SA to Displacement | 38.59 |
| Downwind SA to Displacement | 88.64 |
| Hull Displacement Speed | 0.11 |
| Displacement to Length (D/L) | 9 |
| Ballast to Displacement (B/D) | 0.4 |
| Capsize Screening Formula (CSF) | 1.97 |
