Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
13.01 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | NYYC 42 |
| First built hull | 2006 |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 13.44 kmh |
| Length overall | 13.01 m |
| Length at waterline | 11.61 m |
| Beam overall | 3.69 m |
| Draft maximum | 2.47 m |
| Displacement | 7,250.21 kg |
| Ballast weight | 3,200.09 kg |
| Ballast type | Lead |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Frers Naval Architecture & Engineering |
| Website | http://www.germanfrers.com |
Rig & Sails
| Spars | Mast in Carbon fiber and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 109.16 sq.m |
| Downwind sail area | 246.38 sq.m |
Engine
| Engine A | |
| Power | 39 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.08 |
| Upwind SA to Displacement | 29.64 |
| Downwind SA to Displacement | 66.9 |
| Hull Displacement Speed | 0.08 |
| Displacement to Length (D/L) | 8.27 |
| Ballast to Displacement (B/D) | 0.44 |
| Capsize Screening Formula (CSF) | 1.92 |
