Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
14.36 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | NYYC 48 Fin keel |
| First built hull | 1974 |
| Version | Fin keel |
| Boat type | Sail |
| Category | Cruiser BoatsCenter Cockpit Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.99 kmh |
| Mast height | 20.15 m |
| Length overall | 14.36 m |
| Length at waterline | 11.09 m |
| Beam overall | 4.21 m |
| Draft maximum | 2.35 m |
| Displacement | 14,700.01 kg |
| Ballast weight | 6,999.83 kg |
| Ballast type | Lead |
| Helm | 1 wheel |
| Rudder | 1 rudder on skeg |
| Cockpit | Twin cockpit (central and closed aft) |
Designer
| Naval architect | |
| Name/Studio | Drake Sparkman ; Olin Stephens |
| Website | http://www.sparkmanstephens.com/ |
Rig & Sails
| Mast | 66.1 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | Single-strand (ROD) discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 126.91 sq.m |
| Downwind sail area | 246.38 sq.m |
Engine
| Engine A | |
| Power | 61 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 21.51 |
| Downwind SA to Displacement | 41.76 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 8.08 |
| Ballast to Displacement (B/D) | 0.48 |
| Capsize Screening Formula (CSF) | 1.73 |
