Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
35.23 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | Swan 115 S Standard |
| First built hull | 2015 |
| Version | Standard |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 22.39 kmh |
| Length overall | 35.23 m |
| Length at waterline | 32.86 m |
| Beam overall | 8.14 m |
| Draft maximum | 4.72 m |
| Displacement | 113,387.11 kg |
| Ballast weight | 32,000.01 kg |
| Ballast type | Cast iron |
| Helm | 2 wheels |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Frers Naval Architecture & Engineering |
| Website | http://www.germanfrers.com |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Spreaders angle | Swept-back |
| Upwind sail area | 652.74 sq.m |
| Downwind sail area | 978.92 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 450 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 28.34 |
| Downwind SA to Displacement | 42.51 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 13.91 |
| Ballast to Displacement (B/D) | 0.28 |
| Capsize Screening Formula (CSF) | 1.7 |
