Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.7 m
Specs
Main
Name | Value |
---|---|
Maker | Nautor Swan |
Maker website | https://www.nautorswan.com |
Model | Swan 36 |
First built hull | 1967 |
Boat type | Sail |
Category | Cruiser/Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 10.9 kmh |
Length overall | 10.7 m |
Length at waterline | 7.8 m |
Beam overall | 2.96 m |
Headroom | 1.89 m |
Draft maximum | 1.89 m |
Displacement | 6,999.83 kg |
Ballast weight | 3,600.16 kg |
Ballast type | Lead |
Helm | 1 tiller |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Drake Sparkman ; Olin Stephens |
Website | http://www.sparkmanstephens.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | Continuous |
Number of spreaders | 1 |
Spreaders angle | 0 ° |
Upwind sail area | 63.27 sq.m |
Downwind sail area | 122.26 sq.m |
Mainsail A | 229.00 |
Spinnaker A | 1087.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 15 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 17.59 |
Downwind SA to Displacement | 33.98 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 6.78 |
Ballast to Displacement (B/D) | 0.51 |
Capsize Screening Formula (CSF) | 1.56 |
