Specs

Main
MakerNautor Swan
Maker websitehttps://www.nautorswan.com
ModelSwan 37
First built hull1970
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed11.28 kmh
Mast height15.3 m
Length overall11.13 m
Length at waterline8.35 m
Beam overall3.08 m
Draft maximum1.98 m
Displacement7,000 kg
Ballast weight3,300 kg
Ballast typeLead
Helm1 tiller
Rudder1 rudder on skeg
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioDrake Sparkman ; Olin Stephens
Websitehttp://www.sparkmanstephens.com/
Rig & Sails
Mast50.2
SparsMast and boom in Aluminum
Standing riggingSingle-strand (ROD) continous
Number of spreaders1
Spreaders angle0 °
Upwind sail area72.28 sq.m
Downwind sail area142.98 sq.m
Engine
Engine B
Power25 HP
TypeInboard
Storage
Fuel tank A99.93 liter
Water tank A180.19 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 20.08
Upwind SA to Displacement20.08
Downwind SA to Displacement39.73
Hull Displacement Speed 7.01
Displacement to Length (D/L) 334.91
Ballast to Displacement (B/D) 0.47
Capsize Screening Formula (CSF) 1.62
