Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.22 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | Swan 411 |
| First built hull | 1977 |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.49 kmh |
| Length overall | 12.22 m |
| Length at waterline | 10.27 m |
| Beam overall | 3.39 m |
| Draft maximum | 2.26 m |
| Displacement | 10,800.03 kg |
| Ballast weight | 5,199.98 kg |
| Ballast type | Lead |
| Helm | 1 wheel |
| Rudder | 1 rudder on skeg |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Drake Sparkman ; Olin Stephens |
| Website | http://www.sparkmanstephens.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Single-strand (ROD) discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 105.07 sq.m |
| Downwind sail area | 205.97 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 47 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 21.87 |
| Downwind SA to Displacement | 42.88 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.78 |
| Ballast to Displacement (B/D) | 0.48 |
| Capsize Screening Formula (CSF) | 1.55 |
