Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.8 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | Swan 42 Shoal draft |
| First built hull | 1980 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser BoatsCenter Cockpit Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 12.55 kmh |
| Length overall | 12.8 m |
| Length at waterline | 10.09 m |
| Beam overall | 3.96 m |
| Draft maximum | 1.56 m |
| Displacement | 9,500.03 kg |
| Ballast weight | 4,100.02 kg |
| Ballast type | Lead |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Twin cockpit (central and closed aft) |
Designer
| Naval architect | |
| Name/Studio | Ron Holland |
| Website | http://www.ronhollanddesign.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 95.6 sq.m |
| Downwind sail area | 184.88 sq.m |
Engine
| Engine A | |
| Power | 40 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 21.68 |
| Downwind SA to Displacement | 41.92 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.71 |
| Ballast to Displacement (B/D) | 0.43 |
| Capsize Screening Formula (CSF) | 1.89 |
