1974 Nautor Swan Swan 47 Keel and centerboard

1518

Report error

1974 Nautor Swan Swan 47 Keel and centerboard
1974 Nautor Swan Swan 47 Keel and centerboard
1974 Nautor Swan Swan 47 Keel and centerboard
1974 Nautor Swan Swan 47 Keel and centerboard
Preview
1974 Nautor Swan Swan 47 Keel and centerboard
Preview
1974 Nautor Swan Swan 47 Keel and centerboard
Preview

Boat Overview

Specs

Main
NameValue
MakerNautor Swan
Maker websitehttps://www.nautorswan.com
ModelSwan 47 Keel and centerboard
First built hull1974
VersionKeel and centerboard
Boat typeSail
CategoryCruiser BoatsCenter Cockpit Boats
Hull typeMonohull
Hull materialFiberglass
General
NameValue
Top speed12.99 kmh
Mast height20.15 m
Length overall14.36 m
Length at waterline11.09 m
Beam overall4.21 m
Draft maximum1.56 m
Displacement15,500.15 kg
Ballast weight7,799.97 kg
Ballast typeLead
Helm1 wheel
Rudder1 rudder on skeg
CockpitTwin cockpit (central and closed aft)
Designer
NameValue
Naval architect
Name/StudioDrake Sparkman ; Olin Stephens
Websitehttp://www.sparkmanstephens.com/
Rig & Sails
NameValue
Mast66.1
SparsMast and boom in Aluminum
Standing riggingSingle-strand (ROD) discontinuous
Number of spreaders2
Spreaders angle0 °
Upwind sail area126.91 sq.m
Downwind sail area246.38 sq.m
Mainsail A446.00
Spinnaker A2207.00
Engine
NameValue
Engine A
Power61 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement20.76
Downwind SA to Displacement40.31
Hull Displacement Speed 0.05
Displacement to Length (D/L) 8.08
Ballast to Displacement (B/D) 0.5
Capsize Screening Formula (CSF) 1.7
