Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
16.49 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | Swan 54 Keel and centerboard |
| First built hull | 2016 |
| Version | Keel and centerboard |
| Price | 1,100,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 14.82 kmh |
| Length overall | 16.49 m |
| Length at waterline | 14.39 m |
| Beam overall | 4.79 m |
| Draft maximum | 1.43 m |
| Displacement | 26,000 kg |
| Ballast weight | 10,150 kg |
| Ballast type | Lead |
| Helm | 2 wheels |
| Rudder | 2 spade rudders |
| Cockpit | Closing aft cockpit with opening system |
Designer
| Naval architect | |
| Name/Studio | Frers Naval Architecture & Engineering |
| Website | http://www.germanfrers.com |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Number of spreaders | 2 |
| Spreaders angle | 20 ° |
| Upwind sail area | 142.89 sq.m |
| Downwind sail area | 291.07 sq.m |
Engine
| Engine A | |
| Power | 110 HP |
| Type | Inboard |
Storage
| Fuel tank A | 495.13 liter |
| Water tank A | 684.02 liter |
| Holding tank A | 120 liter |
| Water heater A | 49.97 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 16.56 |
| Downwind SA to Displacement | 33.73 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 9.21 |
| Ballast to Displacement (B/D) | 0.39 |
| Capsize Screening Formula (CSF) | 1.63 |
