Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
16.49 m
Specs
Main
Name | Value |
---|---|
Maker | Nautor Swan |
Maker website | https://www.nautorswan.com |
Model | Swan 54 Standard |
First built hull | 2016 |
Version | Standard |
Price | 1,100,000 € |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 14.82 kmh |
Length overall | 16.49 m |
Length at waterline | 14.39 m |
Beam overall | 4.79 m |
Draft maximum | 2.44 m |
Displacement | 25,999.89 kg |
Ballast weight | 8,200.04 kg |
Ballast type | Lead |
Helm | 2 wheels |
Rudder | 1 spade rudder |
Cockpit | Closing aft cockpit with opening system |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Frers Naval Architecture & Engineering |
Website | http://www.germanfrers.com |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Carbon fiber |
Number of spreaders | 2 |
Spreaders angle | 20 ° |
Upwind sail area | 142.89 sq.m |
Downwind sail area | 291.07 sq.m |
Mainsail A | 873.00 |
Spinnaker A | 2260.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 110 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 16.56 |
Downwind SA to Displacement | 33.73 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 9.21 |
Ballast to Displacement (B/D) | 0.32 |
Capsize Screening Formula (CSF) | 1.63 |
