Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
19.72 m
Specs
Main
| Maker | Nautor Swan |
| Maker website | https://www.nautorswan.com |
| Model | Swan 65 Ketch |
| First built hull | 1971 |
| Version | Ketch |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 14.79 kmh |
| Mast height | 24.44 m |
| Length overall | 19.72 m |
| Length at waterline | 14.33 m |
| Beam overall | 5 m |
| Draft maximum | 2.93 m |
| Displacement | 31,799.97 kg |
| Ballast weight | 13,899.87 kg |
| Helm | 1 wheel |
| Rudder | 1 rudder on skeg |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Drake Sparkman ; Olin Stephens |
| Website | http://www.sparkmanstephens.com/ |
Rig & Sails
| Mast | 80.2 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 209.22 sq.m |
| Downwind sail area | 452.35 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 148 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 21.2 |
| Downwind SA to Displacement | 45.84 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 9.19 |
| Ballast to Displacement (B/D) | 0.44 |
| Capsize Screening Formula (CSF) | 1.59 |
