2019 Neel Trimarans Neel 47

1451

0

2019 Neel Trimarans Neel 47
Preview

Boat Overview

  • Type
    sail
  • Maker
    Neel Trimarans
  • Hull type
    trimaran
  • Hull Material
    composite_material
  • Category
    -
  • Boat length (LOA)
    14.23 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerNeel Trimarans
Maker websitehttps://www.neel-trimarans.com/B61
ModelNeel 47
First built hull2019
Last built hull-
Version-
Price-
Boat typesail
Category-
Hull typetrimaran
Hull materialcomposite_material
Cabins-
Births-
Heads-
General
NameValue
Top speed-
Cruising speed-
Mast height19.02 m
Length overall14.23 m
Length at waterline-
Beam overall8.29 m
Beam center-line-
Beam hull-
Headroom-
Bridgedeck clearance-
Nominal bridgedeck clearance-
Draft maximum1.58 m
Draft minimum-
Displacement10598.19 kg
Tonnage Gross-
Tonnage Net-
Ballast weight-
Ballast type-
Helm1 wheel
Rudder1 spade rudder
Hull appendages
Hull appendages A-
CockpitOpen aft cockpit
Unsinkable-
Trailerable-
CE classification
CE classification A-
CE classification B-
CE classification C-
CE classification D-
Designer
NameValue
Naval architect
Name/StudioMarc Lombard
Websitehttp://www.marclombard.com/
Exterior designer
Name/Studio-
Website-
Interior designer
Name/Studio-
Website-
Rig & Sails
NameValue
Riggingsloop
Rotating spars
Mast62.4
SparsMast and boom in Aluminum
Standing rigging-
Number of spreaders2
Spreaders angleSwept-back (diamond)
Upwind sail area120.03 sq.m
Downwind sail area69.96 sq.m
Mainsail
Mainsail A-
Headsail
Headsail A-
Spinnaker
Spinnaker A-
Engine
NameValue
Engine A
Maker-
Website-
Model-
TypeInboard engine ; Diesel
Drive-
Fuel-
Power60
Power Typehp
Engine B
Maker-
Website-
Model-
Type-
Drive-
Fuel-
Power-
Power Typehp
Storage
NameValue
Fuel tank
Fuel tank A300.15 liter
Water tank
Water tank A599.92 liter
Holding tank
Holding tank A-
Water heater
Water heater A-

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) -
Upwind SA to Displacement25.3
Downwind SA to Displacement14.75
Hull Displacement Speed -
Displacement to Length (D/L) -
Ballast to Displacement (B/D) -
Capsize Screening Formula (CSF) 3.81
Stability Speed-
Kelsall Stability Index (KSI)-
