Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.74 m
Specs
Main
| Maker | Neo Yachts |
| Maker website | https://www.neoyachts.com |
| Model | Neo 400 Plus Lifting keel |
| First built hull | 2014 |
| Version | Lifting keel |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 13.24 kmh |
| Length overall | 12.74 m |
| Length at waterline | 11.52 m |
| Beam overall | 3.99 m |
| Draft maximum | 2.77 m |
| Displacement | 5,199.98 kg |
| Ballast weight | 2,500.2 kg |
| Ballast type | Steel fin with lead bulb |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Giovanni Ceccarelli |
| Website | http://www.ceccarelliyachtdesign.com/ |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 64.01 sq.m |
| Downwind sail area | 230.03 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 30 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.09 |
| Upwind SA to Displacement | 21.69 |
| Downwind SA to Displacement | 77.95 |
| Hull Displacement Speed | 0.09 |
| Displacement to Length (D/L) | 8.24 |
| Ballast to Displacement (B/D) | 0.48 |
| Capsize Screening Formula (CSF) | 2.33 |
