Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11 m
Specs
Main
| Maker | Chantier Ofcet |
| Model | Ofcet 32 SC |
| First built hull | 2016 |
| Version | SC |
| Price | 120,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.83 kmh |
| Mast height | 15.42 m |
| Length overall | 11 m |
| Length at waterline | 9.17 m |
| Beam overall | 3.35 m |
| Beam hull | 1.83 m |
| Draft maximum | 1.98 m |
| Displacement | 3,200 kg |
| Ballast weight | 1,300 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Marc Lombard Yacht Design Group |
| Website | http://www.marclombard.com/ |
Rig & Sails
| Mast | 50.6 |
| Spars | Mast and boom in Carbon fiber |
| Standing rigging | Standard |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 57.97 sq.m |
| Downwind sail area | 120.96 sq.m |
Engine
| Engine B | |
| Power | 18 HP |
| Type | Inboard |
Storage
| Fuel tank A | 40.13 liter |
| Water tank A | 90.09 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 27.15 |
| Downwind SA to Displacement | 56.65 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.35 |
| Ballast to Displacement (B/D) | 0.41 |
| Capsize Screening Formula (CSF) | 2.3 |
