Boat Overview
Type
Maker
Hull type
Hull Material
Aluminium
Category
Boat length (LOA)
10.24 m
Specs
Main
| Maker | Pouvreau |
| Model | Romanée Shoal draft |
| First built hull | 1973 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Aluminium |
General
| Top speed | 11.06 kmh |
| Length overall | 10.24 m |
| Length at waterline | 7.99 m |
| Beam overall | 3.54 m |
| Beam hull | 1.83 m |
| Draft maximum | 1.58 m |
| Displacement | 4,599.88 kg |
| Ballast weight | 1,650.17 kg |
| Helm | 1 tiller |
| Rudder | 1 rudder on skeg |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Philippe Harlé |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 62.9 sq.m |
| Downwind sail area | 109.44 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 27 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 23.13 |
| Downwind SA to Displacement | 40.24 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 6.86 |
| Ballast to Displacement (B/D) | 0.36 |
| Capsize Screening Formula (CSF) | 2.15 |
