Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.36 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Premier Composite Technologies |
| Maker website | http://www.pct.ae/ |
| Model | Farr 280 |
| First built hull | 2013 |
| Price | 102,000 € |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Name | Value |
|---|---|
| Top speed | 11.06 kmh |
| Length overall | 10.36 m |
| Length at waterline | 8.05 m |
| Beam overall | 2.9 m |
| Draft maximum | 1.86 m |
| Displacement | 1,599.82 kg |
| Ballast weight | 650 kg |
| Ballast type | Steel fin with lead bulb |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Farr Yacht Design |
| Website | http://www.farrdesign.com |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast in Carbon fiber and boom in Aluminum |
| Standing rigging | Dyform |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 52.58 sq.m |
| Downwind sail area | 139.17 sq.m |
| Mainsail A | 347.00 |
| Spinnaker A | 1152.00 |
| Spinnaker A | 220.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 20 HP |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.12 |
| Upwind SA to Displacement | 39.09 |
| Downwind SA to Displacement | 103.47 |
| Hull Displacement Speed | 0.12 |
| Displacement to Length (D/L) | 6.89 |
| Ballast to Displacement (B/D) | 0.41 |
| Capsize Screening Formula (CSF) | 2.5 |
