Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
11.83 m
Specs
Main
| Maker | Premier Composite Technologies |
| Maker website | http://www.pct.ae/ |
| Model | Farr 400 |
| First built hull | 2010 |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 13.02 kmh |
| Length overall | 11.83 m |
| Length at waterline | 11.16 m |
| Beam overall | 3.41 m |
| Draft maximum | 2.93 m |
| Displacement | 3,919.94 kg |
| Ballast weight | 2,179.96 kg |
| Ballast type | Steel fin with lead bulb |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Farr Yacht Design |
| Website | http://www.farrdesign.com |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Number of spreaders | 2 |
| Spreaders angle | 22 ° |
| Upwind sail area | 102.01 sq.m |
| Downwind sail area | 235.04 sq.m |
Engine
| Engine A | |
| Power | 27 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.12 |
| Upwind SA to Displacement | 41.73 |
| Downwind SA to Displacement | 96.16 |
| Hull Displacement Speed | 0.12 |
| Displacement to Length (D/L) | 8.11 |
| Ballast to Displacement (B/D) | 0.56 |
| Capsize Screening Formula (CSF) | 2.19 |
