2015 Quorning Boats Dragonfly 25 - Touring
Preview

Boat Overview

  • Type
    sail
  • Maker
    Quorning Boats
  • Hull type
    trimaran
  • Hull Material
    fiberglass
  • Category
    -
  • Boat length (LOA)
    7.65 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerQuorning Boats
Maker websitehttp://dragonfly.dk/
ModelDragonfly 25 - Touring
First built hull2015
VersionTouring
Price72000 EUR
Boat typesail
Hull typetrimaran
Hull materialfiberglass
General
NameValue
Length overall7.65 m
Length at waterline7.53 m
Beam overall5.79 m
Headroom1.25 m
Draft maximum1.25 m
Displacement1049.89 kg
Designer
NameValue
Name/StudioJens Quorning
Websitehttp://www.trimarans.com/
Rig & Sails
NameValue
Riggingfractional_rig_sloop
SparsMast and boom in Aluminum
Standing riggingContinuous
Number of spreaders1
Spreaders angleSwept-back (diamond)
Upwind sail area34.00 sq.m
Downwind sail area69.03 sq.m
Mainsail A258.00
Spinnaker A484.00
Spinnaker A108.00
Engine
NameValue
TypeOutboard ; Gas
Power6 HP
Storage
NameValue
No Data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 23.59
Upwind SA to Displacement33.47
Downwind SA to Displacement67.95
Hull Displacement Speed 6.66
Displacement to Length (D/L) 68.58
Capsize Screening Formula (CSF) 5.75
