Specs

Main
MakerDragonfly
Maker websitehttps://www.dragonfly.dk
ModelDragonfly 32 - Touring
First built hull2012
VersionTouring
Price239,000 €
Boat typeSail
CategoryTrimaran Boats
Hull typeTrimaran
Hull materialFiberglass
General
Length overall9.81 m
Length at waterline9.51 m
Beam overall7.99 m
Beam hull1.95 m
Draft maximum1.89 m
Displacement4,500 kg
Helm1 tiller (helm wheel in option)
Rudder1 transom hung rudder (main hull)
CockpitClosed aft cockpit
Unsinkable
Designer
Naval architect
Name/StudioJens Quorning ; Steen Olsen
Websitehttp://olsendesign.dk/
Rig & Sails
Rotating spars
SparsMast in Carbon fiber and boom in Aluminum
Number of spreaders2
Spreaders angleSwept-back (diamond)
Upwind sail area70.98 sq.m
Downwind sail area124.03 sq.m
Engine
Engine A
Power30 HP
TypeOutboard
Storage
Fuel tank A24.98 liter
Water tank A120 liter
Holding tank A60.19 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 26.48
Upwind SA to Displacement26.48
Downwind SA to Displacement46.26
Hull Displacement Speed 7.48
Displacement to Length (D/L) 145.83
Capsize Screening Formula (CSF) 4.88
