2008 Dragonfly Dragonfly 28 - Performance

No gallery images

Boat Overview

Type
Sail
Maker
Dragonfly
Hull type
Trimaran
Hull Material
Fiberglass
Category
Trimaran Boats
Boat length (LOA)
9.08 m
See all details

Overview

Performance & Ratios

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Hide empty fields

Main

Name	Value
Maker	Dragonfly
Maker website	https://www.dragonfly.dk
Model	Dragonfly 28 - Performance
First built hull	2008
Version	Performance
Price	153,000 €
Boat type	Sail
Category	Trimaran Boats
Hull type	Trimaran
Hull material	Trimaran

General

Name	Value
Mast height	15.24 m
Length overall	9.08 m
Length at waterline	8.6 m
Beam overall	6.52 m
Headroom	1.86 m
Draft maximum	1.74 m
Displacement	2,725.18 kg
Helm	1 tiller
Rudder	1 transom hung rudder (main hull)
Cockpit	Closed aft cockpit
Unsinkable
Trailerable

Designer

Name	Value
Naval architect
Name/Studio	Jens Quorning ; Steen Olsen
Website	http://olsendesign.dk/

Rig & Sails

Name	Value
Rotating spars
Mast	50
Spars	Mast in Carbon fiber and boom in Aluminum
Number of spreaders	2
Spreaders angle	Swept-back (diamond)
Upwind sail area	64.01 sq.m
Downwind sail area	125.98 sq.m
Mainsail A	463.00
Spinnaker A	893.00
Spinnaker A	226.00
Spinnaker A	484.00

Engine

Name	Value
Engine A
Power	15 HP
Type	Outboard ; Gas
Engine B

Storage

Name	Value
No data

Performance & Ratios

Hide empty fields

Detail

Name	Value
Sail Area to Displacement (SA/D)	22.42
Upwind SA to Displacement	33.37
Downwind SA to Displacement	65.67
Hull Displacement Speed	7.12
Displacement to Length (D/L)	119.6
Capsize Screening Formula (CSF)	4.71
