Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.08 m
Specs
Main
Name | Value |
---|---|
Maker | Dragonfly |
Maker website | https://www.dragonfly.dk |
Model | Dragonfly 28 - Touring |
First built hull | 2008 |
Version | Touring |
Price | 138,000 € |
Boat type | Sail |
Category | Trimaran Boats |
Hull type | Trimaran |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Mast height | 13.75 m |
Length overall | 9.08 m |
Length at waterline | 8.6 m |
Beam overall | 6.52 m |
Headroom | 1.86 m |
Draft maximum | 1.74 m |
Displacement | 2,624.94 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder (main hull) |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Jens Quorning ; Steen Olsen |
Website | http://olsendesign.dk/ |
Rig & Sails
Name | Value |
---|---|
Rotating spars | |
Mast | 45.1 |
Spars | Mast and boom in Aluminum |
Number of spreaders | 2 |
Spreaders angle | Swept-back (diamond) |
Upwind sail area | 53.98 sq.m |
Downwind sail area | 99.96 sq.m |
Mainsail A | 377.00 |
Spinnaker A | 700.00 |
Spinnaker A | 205.00 |
Spinnaker A | 377.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 15 HP |
Type | Outboard ; Gas |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.06 |
Upwind SA to Displacement | 28.85 |
Downwind SA to Displacement | 53.43 |
Hull Displacement Speed | 0.06 |
Displacement to Length (D/L) | 7.12 |
Capsize Screening Formula (CSF) | 4.77 |
