2012 Quorning Boats Dragonfly 32 - Supreme
Preview

Boat Overview

  • Type
    sail
  • Maker
    Quorning Boats
  • Hull type
    trimaran
  • Hull Material
    fiberglass
  • Category
    -
  • Boat length (LOA)
    9.81 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerQuorning Boats
Maker websitehttp://dragonfly.dk/
ModelDragonfly 32 - Supreme
First built hull2012
VersionSupreme
Price254000 EUR
Boat typesail
Hull typetrimaran
Hull materialfiberglass
General
NameValue
Length overall9.81 m
Length at waterline9.51 m
Beam overall7.99 m
Headroom1.95 m
Draft maximum1.89 m
Displacement4499.32 kg
Helm1 tiller (helm wheel in option)
Rudder1 transom hung rudder (main hull)
CockpitClosed aft cockpit
Designer
NameValue
Name/StudioJens Quorning ; Steen Olsen
Websitehttp://olsendesign.dk/
Rig & Sails
NameValue
Riggingfractional_rig_sloop
SparsMast in Carbon fiber and boom in Aluminum
Number of spreaders2
Spreaders angleSwept-back (diamond)
Upwind sail area85.01 sq.m
Downwind sail area164.99 sq.m
Mainsail A592.00
Spinnaker A1184.00
Engine
NameValue
TypeOutboard or inboard engine ; Gas
Power30 HP
Storage
NameValue
No Data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 20.52
Upwind SA to Displacement31.72
Downwind SA to Displacement61.57
Hull Displacement Speed 7.48
Displacement to Length (D/L) 145.83
Capsize Screening Formula (CSF) 4.88
